Description
Applications
- Effluent pumping in industrial wastewater treatment plants.
- Sewage wastewater and solid treatment in various factories and building sites.
- Food processing factory.
- Confined livestock feeding industry.
- Pulp and paper factory.
- Residential houses.
- Restaurants and shops.
- Markets and supermarkets.
Performance Curve
Model | Motor | Pump | ||||||||
Power | Phase | Volt | Revolution | Pump Outlet Discharge | Max. Head | Max. Flow | Solid Passage | |||
HP | KW | PH | V | Rpm | Inch | Mm | Ft | Gal/Min | Inch | |
GFO-2032S | 20 | 15 | 3 | 230/460V | 1800 | 6 | 150 | 111.5 | 1320 | 4.6 x 2 |
Dimensions
Size (inch) | Weight (lbs.) | ||||||
A | B | C | D | E | F | G | |
34.6 | 29.1 | 19.3 | 15.9 | 12.2 | 32.2 | 35.5 | 578.6 |
