Model | 6OP65/4 |
Brand | Saer-USA |
Manufacturer’s Warranty | 1 year Limited Warranty |
Diffuser body
Impeller Material |
Stainless Steel AISI304
Stainless Steel AISI304 |
Port Size (in.) | 2-1/2 |
Flow (GPH) | 12720 |
HP
KW |
18.3
13.5 |
Volts | 460V – Three phase |
Amps | 22.5 |
Max. Total Head (ft.) | 489 |
Max. Suction Lift (ft.) | 17 |
Max. PSI | 216 |
Suction Port (in.) | 2-1/2 |
Discharge Port (in.) | 2-1/2 |
Self-Priming | No |
Dimensions L x W x H (in.) | 36 x 12.3 x 10.3 |
Product Weight (lbs.) |
