Description
Application:
Selfpriming jet water pumps with a very high hydraulic perfor-mance and a considerable pressure capacity. Able to pump up to mt. 8 depth and work perfectly even in soda-water. Suitable for drinkable water, water lifting and distribution in domestic fittings by small and medium sized tanks.
Brand: SPERONI
MADE IN ITALY
OPERATING CONDITIONS:
- – Liquid temperature up to 95°F (for home use according to EN 60335-2-41)
- – Temperature max. liquid: 95°F (for other uses)
- – Ambient temperature up to 104°F
- – Total suction lift up to 26.2 ft.
MOTOR
- – Single-phase 110/230V-60Hz
- – Insulation Class F
- – Protection IP 44
MATERIALS
- – Pump body: Stainless Steel 304
- – Motor Support: Aluminium
- – Impeller: Noryl
- – Diffuser: Noryl
- – Pump flange: Stainless Steel 304
- – Shaft with rotor: Stainless Steel 304
- – Mechanical seal: Ceramic/Graphite/NBR
More Details:
Model | CAM88 |
Brand | SPERONI |
Manufacturer’s Warranty | 1 year Limited Warranty |
Impeller Material | Noryl |
Port Size (in.) | 1 |
Flow (GPH) | 792 |
HP | 1 |
Volts
AMP |
110/220V – 1 Phase
11.5/5.0 |
Max. Total Head (ft.) | 151 |
Max. Suction Lift (ft.) | 26.2 |
Max. PSI | 66.7 |
Suction Port (in.) | 1 |
Discharge Port (in.) | 1 |
Self-Priming | Yes |
Dimensions L x W x H (in.) | 14.5 x 7 x 8 |
Product Weight (lbs.) | 22.5 |
